Product Features
Reject cutting:The coating performance is stable; Suitable for high temperature environments and less prone to wear and tear;
Extremely Sharp:Modern grinding machine equipment, high-precision sharpening, full sharpening of blades, no slight defects, cutting iron like mud;
Powerful:It can directly perform the entire process from rough milling to fine milling without the need for tool replacement;
Farewell to Sticky Knife:35 ° Spiral Angle& Large core diameter design significantly improves production efficiency;
Suitable for processing materials: stainless steel, ductile iron, alloy steel, mold steel, steel alloys, etc;
Product Parameters
Name | Specification /Pitch | Stem Diameter | Blade Diameter | Length | Blade Count | Total Length | Threaded Bottom Hole | |
Alloy thread milling cutter | M1.0*0.25 coarse teeth | steel | 4 | 0.73 | 2.3 | 3 | 50 | 0.75 |
Alloy thread milling cutter | M1.2*0.25 coarse teeth | steel | 4 | 0.92 | 2.8 | 3 | 50 | 0.95 |
Alloy thread milling cutter | M1.4*0.3 coarse teeth | steel | 4 | 1.05 | 3.2 | 3 | 50 | 1.15 |
Alloy thread milling cutter | M1.6*0.35 coarse teeth | steel | 4 | 1.20 | 3.4 | 3 | 50 | 1.25 |
Alloy thread milling cutter | M1.8*0.35 coarse teeth | steel | 4 | 1.40 | 4.0 | 3 | 50 | 1.5 |
Alloy thread milling cutter | M2.0*0.4 coarse teeth | steel | 4 | 1.55 | 4.2 | 3 | 50 | 1.6 |
Alloy thread milling cutter | M2.2*0.45 coarse teeth | steel | 4 | 1.65 | 4.6 | 3 | 50 | 1.75 |
Alloy thread milling cutter | M2.5*0.45 coarse teeth | steel | 4 | 1.95 | 5.2 | 3 | 50 | 2.05 |
Alloy thread milling cutter | M3.0*0.5 coarse teeth | steel | 4 | 2.40 | 6.2 | 3 | 50 | 2.5 |
Alloy thread milling cutter | M3.5*0.6 coarse teeth | steel | 4 | 2.75 | 7.3 | 3 | 50 | 2.9 |
Alloy thread milling cutter | M4.0*0.7 coarse teeth | steel | 4 | 3.15 | 8.3 | 3 | 50 | 3.3 |
Alloy thread milling cutter | M5.0*0.8 coarse teeth | steel | 6 | 4.05 | 10.4 | 3 | 50 | 4.2 |
Alloy thread milling cutter | M6.0*1.0 coarse teeth | steel | 6 | 4.80 | 12.5 | 3 | 50 | 5.0 |
Alloy thread milling cutter | M8.0*1.25 coarse teeth | steel | 8 | 6.50 | 16.6 | 4 | 60 | 6.8 |
Alloy thread milling cutter | M10*1.5 coarse teeth | steel | 10 | 8.20 | 20.8 | 4 | 75 | 8.5 |
Alloy thread milling cutter | M12*1.75 coarse teeth | steel | 10 | 9.90 | 25.0 | 4 | 75 | 10.2 |
Alloy thread milling cutter | M14*2.0 coarse teeth | steel | 12 | 11.60 | 30.0 | 4 | 75 | 12 |
Alloy thread milling cutter | M16*2.0 coarse teeth | steel | 12 | 11.90 | 33.0 | 4 | 80 | 14 |
Alloy thread milling cutter | M20*2.5 coarse teeth | steel | 16 | 15.90 | 41.3 | 5 | 100 | 17.5 |
