Product Features
Powerful:Blade Through Center& The blade is designed with seismic resistance and can directly process high hardness materials such as heat-resistant alloys and quenched parts;
Refuse to break the knife:One shot forming of high hardness blue nanocomposite coating on overall tungsten steel;
Extremely sharp:Fully sharpened blade without any slight flaws, cutting iron like mud;
Farewell to Sticky Knife:35 ° Spiral Angle& Large core diameter design;
Suitable for processing materials: ordinary steel, carbon steel, alloy steel, pre hardened steel, mold steel, quenched and tempered steel, high hardness materials, stainless steel, heat-resistant titanium alloy, cast iron, copper alloy, graphite, CFRP;
Product Parameters
Name:65°70° 2-blade ball knife | Cutting hardness:HRC65°70° |
Coating: High hardness nanocomposite coating | Spiral angle:35° |
Product Name | Blade radius | Blade length | Stem diameter | Length |
R0.5×50 | R0.5 | 2C | D4 | 50L |
R0.75×50 | R0.75 | 3C | D4 | 50L |
R1×50 | R1 | 4C | D4 | 50L |
R1.25×50 | R1.25C | 5C | D4 | 50L |
R1.5×50 | R1.5 | 6C | D3 | 50L |
R1.5×50 | R1.5 | 6 | D4 | 50L |
R1.75×50 | R1.75 | 7C | D4 | 50L |
R2×50 | R2 | 8C | D4 | 50L |
R2×75 | R2 | 8C | D4 | 75L |
R2×100 | R2 | 8C | D4 | 100L |
R2.5×50 | R2.5 | 10C | D5 | 50L |
R2.5×50 | R2.5 | 10C | D6 | 50L |
R2.5×75 | R2.5 | 10C | 5D | 75L |
R2.5×100 | R2.5 | 10C | 5D | 100L |
R3×50 | R3 | 12C | D6 | 50L |
R3×75 | R3 | 12C | D6 | 75L |
R3×100 | R3 | 12C | D6 | 100L |
R4×60 | R4 | 16C | D8 | 60L |
R4×75 | R4 | 16C | D8 | 75L |
R4×100 | R4 | 16C | D8 | 100L |
R5×75 | R5 | 20C | D10 | 75L |
R5×100 | R5 | 20C | D10 | 100L |
R6×75 | R6 | 24C | D12 | 75L |
R6×100 | R6 | 24C | D12 | 100L |
R7×100 | R7 | 28C | D14 | 100L |
R8×100 | R8 | 32C | D16 | 100L |
R9×100 | R9 | 36C | D18 | 100L |
R10×100 | R10 | 40C | D20 | 100L |
R3×150 | R3 | 12C | D6 | 150L |
R4×150 | R4 | 16C | D8 | 150L |
R5×150 | R5 | 20C | D10 | 150L |
R6×150 | R6 | 24C | D12 | 150L |
R7×150 | R7 | 28C | D14 | 150L |
R8×150 | R8 | 32C | D16 | 150L |
R9×150 | R9 | 36C | D18 | 150L |
